DIN 1.4404 Tubes
ASME SA213 DIN 1.4404 Stainless Steel Tubes Exporter, DIN 1.4404 Cold Rolled (CR) Tubes, DIN 1.4404 ERW Tubes, DIN 1.4404 EFW Tubes, Stainless Steel DIN 1.4404 Polished Tube, DIN 1.4404 Electropolished Tube Supplier & Stockists
Leoscor Alloys has been a premier leader in the field of stainless steel tube manufacturing for the past many years. We manufacture high-grade DIN 1.4404 Tubes, which are stocked at our vast inventory, and are then exported, to our vast base of national and international customers, as per their time demands. DIN 1.4404 Stainless Steel Tubing is basically prepared from the high grade of stainless steel. Not only do our DIN 1.4404 Tubing show excellent corrosion resistance in ordinary atmospheres, but they also showcase superior corrosion resistance characters in various arduous environments.
We take extra care while manufacturing the 310 Stainless Steel Tubes to ensure that it doesn’t have any welded joints or any other kind of abruptness on the surface of the tubes. The UNS S31000 Tubes are manufactured under proper temperature conditions and also carry superior corrosion resistance properties.
Our DIN 1.4404 tubes and DIN 1.4404 EFW tubes are always highly demanded in various markets like pipelines, heat exchangers, pressure vessels, submarines, and much more. These are produced in accordance with the quality standards. DIN 1.4404 Electropolished tubes have a very smooth surface and proper finish. Stainless Steel Tubes are produced by us by the extrusion die process, under strict room temperature conditions.
To supply all our customers with their specifically desired products in a punctual and efficient manner, we make sure that the Stainless Steel DIN 1.4404 Tubing manufactured by us are available in a variety of shapes like round, square, rectangular, oval, hollow, etc., and in different forms like threaded, hot rolled, cold rolled, ERW, EFW heat exchangers, annealed, pickled, etc. Please contact us or email us today a free quote!
Stainless Steel DIN 1.4404 Round Tubes Stockist, ASTM A213 DIN 1.4404 Square Tubes, DIN 1.4404 SS Rectangular Tubes, DIN 1.4404 Hollow Tubes Stockholder, Stainless Steel DIN 1.4404 Hexagonal Tubes Wholesaler, Provider
DIN 1.4404 Tubes - Quick Section Links
SS DIN 1.4404 Tubes Specifications
Standard specifications for stainless steel SS DIN 1.4404 Tubes. If any specification is not mentioned here, you can contact us. We also manufacture and export any custom specification as per clients requirement.
Specifications | ASTM A/ASME SA213/A249/A269 |
Dimensions | ASTM, ASME and API |
DIN 1.4404 Tubes | 1/8″NB TO 30″NB IN |
Thickness | 0.35mm to 6.35mm OD in thickness ranging from 0.1mm to 1.2mm. |
Schedule | SCH20, SCH30, SCH40, STD, SCH80, XS, SCH60, SCH80, SCH120, SCH140, SCH160, XXS |
Type | Seamless / ERW / Welded / Fabricated / LSAW Tubes |
Form | Round, Square, Rectangular, Hydraulic Etc |
Length | Single Random, Double Random & Cut Length. |
End | Plain End, Beveled End, Treaded |
Types of SS DIN 1.4404 Tubes
Stainless Steel DIN 1.4404 Welded Tubes | DIN 1.4404 SS Welded Tubes |
DIN 1.4404 SS Seamless Tubes | Stainless Steel DIN 1.4404 Seamless Tubes |
Stainless Steel DIN 1.4404 ERW Tubes | DIN 1.4404 SS ERW Tubes |
DIN 1.4404 SS Fabricated Tubes | Stainless Steel DIN 1.4404 Fabricated Tubes |
Stainless Steel DIN 1.4404 LSAW Tubes | DIN 1.4404 SS LSAW Tubes |
DIN 1.4404 Stainless Steel Polished Tubes | SS DIN 1.4404 Polished Tubes |
Stainless Steel DIN 1.4404 Cold Drawn Tubes | DIN 1.4404 SS Cold Drawn Tubes |
DIN 1.4404 SS Hot Rolled Tubes | Stainless Steel DIN 1.4404 Hot Rolled Tubes |
Stainless Steel DIN 1.4404 Cold Rolled Tubes | DIN 1.4404 SS Cold Rolled Tubes |
DIN 1.4404 SS Square Tubes | Stainless Steel DIN 1.4404 Round Tubes |
Stainless Steel DIN 1.4404 Hexagonal Tubes | DIN 1.4404 Stainless Steel Tubes |
DIN 1.4404 Seamless Tubes Chemical Composition
Grade | 1.4404 | |
---|---|---|
min | max | |
C | – | 0.035 |
Mn | – | 2.0 |
Si | – | 0.75 |
P | – | 0.045 |
S | – | 0.030 |
Cr | 16.0 | 18.0 |
Mo | 2.0 | 3.0 |
Ni | 10.0 | 14.0 |
N | – | – |
ASTM A213 DIN 1.4404 SS Welded Tubes Mechanical Properties
Grade | DIN 1.4404 | |
---|---|---|
Tensile Strength (MPa) min | 485 | |
Yield Strength 0.2% Proof (MPa) min | 170 | |
Elongation (% in 50mm) min | 40 | |
Hardness | Rockwell B (HR B) max | 95 |
Brinell (HB) max | 217 |
SS DIN 1.4404 Tubes Physical Properties
Grade | DIN 1.4404 | |
---|---|---|
Density (kg/m3) | 8000 | |
Elastic Modulus (GPa) | 193 | |
Mean Coefficient of Thermal Expansion (m/m/0C) | 0-1000C | 15.9 |
0-3150C | 16.2 | |
0-5380C | 17.5 | |
Thermal Conductivity (W/m.K) | at 1000C | 16.3 |
at 5000C | 21.5 | |
Specific Heat 0-1000C (J/kg.K) | 500 | |
Electrical Resistivity (n.m) | 740 |
Stainless Steel DIN 1.4404 Tubes Equivalent Grades
Grade | 316L | |
UNS No | S31603 | |
Old British | BS | 316S11 / 316S13 |
En | X2CrNiMo17-12-2 / X2CrNiMo18-14-3 | |
Euronorm | No | 1.4404 / 1.4435 |
AFNOR | Z3CND17-11-02 / Z3CND18-04-03 | |
Swedish SS | – | |
Japanese JIS | SUS 316L | |
GOST | 03Ch17N14M3 / 03Ch17N14M2 |
DIN 1.4404 Tubes Price List
Leoscor Alloys is one of the most competitive suppliers of pipes and tubes from India. Our prices for SS DIN 1.4404 Tubes are very competitive.
Please click on the request a quote button or click here to request the updated price list and ready stock information along with your requirement. Leoscor Alloys maintains a stock of all standard items and can export them at best price for DIN 1.4404 Stainless Steel Seamless and Welded Tubes.
SS DIN 1.4404 Welded Tubes - Industries & Applications
Our pipes and tubes are used in a wide range of applications and various industries. Below are a few of them:
- Gas Processing Industries
- Petrochemical Industries
- Power Generation Industries
- Food Processing Industries
- Chemical Industries
- Oil & Gas Industries
- Fertilizers Industries
- Sugar Industries
ASTM A213 Stainless Steel DIN 1.4404 Tube Stock Availability
We maintain huge inventories of all standard sizes and grades. Please send us your complete requirement and we will send you the availability with the best quote for DIN 1.4404 Tubes.
Why Buy DIN 1.4404 SS Tubes from Leoscor Alloys
Leoscor Alloys is a leading stockist, distributor, and supplier of 1.4404 DIN SS Tubes from India. With more than three decades of experience, we understand the steel industry deeply. We have huge experience of supplying to all major industries across the world. Our team of dedicated experts with stringent quality policy ensures that we supply best-in-class products meeting and exceeding our client’s expectations. Below are a few quick points about why buying from Leoscor Alloys will give you an undue advantage:
- Huge inventory of all standard sizes and grades.
- Distributors of all reputed origins and manufacturers.
- Strict quality control policies and highly experienced team.
- Strong logistics & delivery channels.
- Modern Infrastructure with huge storage capacity.
- An ISO 9000:2015 Certified Company.
