API 5L IBR Pipe

Home API 5L IBR Pipe

API 5L IBR Pipe

Carbon Steel API 5L IBR Line Pipes Dealers, API 5L IBR Welded Pipes, API 5L IBR Round Pipes, API 5L PSL 2 Square Pipes, API 5L IBR Hollow Pipes, API 5L IBR Seamless Round Pipes Stockists in India

We are actively engaged in offering a wide gamut of API 5L GR B IBR Pipes & Tubes. These are manufactured using high-grade material and the latest technology with set universal standards. Additionally, offered products are checked against various parameters of quality under the strict supervision of quality controllers to ensure flawless deliveries. In addition to this, these can also be customized as per various specifications from our prestigious clients.

Looking for a Carbon Steel IBR Seamless Pipes Supplier? We can help supply the greater part of the Carbon Steel IBR Pipes or line pipes supplies that your organization requires for use in the oil or gaseous petrol enterprises. All items are industry-standard fitting in with or surpassing API, ASTM, ASME, ANSI, and other national and global models.

Programming interface 5L Line Pipe Specifications for these channels direct utilization for standard Grade An and Grade B pipes, with Grade X showing more grounded variations for boring, creation and transport necessities for seaward, ice, profound well or harsher situations.

We procure Carbon Steel Pipes from well-known Maker i.e. ISMT, JSL, MSL with IBR Form III in Original. On receipt of the material, the same is offered for Inspection to the local IBR Inspector. We Provide Line wise material identification report For piping used for transportation of team BFW Condensate Line wise Hydro Test Report is been prepared & stamped & signed by the IBR Inspector.

API 5L IBR Pipe - Quick Section Links

API 5L IBR Pipe

API 5L IBR Pipe
API 5L IBR Pipe

API 5L IBR Carbon Steel Pipe Specifications

Standard specifications for stainless steel API 5L IBR Pipe. If any specification is not mentioned here, you can contact us. We also manufacture and export any custom specification as per clients requirement.

Standard ASTM A 53, A106 Gr. B, API 5L GR.B, API 5L X 42.
Size 1/2″NB TO 24″NB IN
Type Seamless
Length Single Random, Double Random & Cut Length.
End Plain End, Beveled End
Schedule SCH20, SCH30, SCH40, STD, SCH60, SCH80, SCH120, SCH140, SCH160, XXS

Types of API 5L IBR CS Pipe

CS API 5L IBR Welded Pipe Carbon Steel API 5L IBR Welded Pipe
API 5L IBR Welded Carbon Steel Pipe CS API 5L IBR Seamless Pipe
Carbon Steel API 5L IBR Seamless Pipe API 5L IBR Seamless Carbon Steel Pipe
CS API 5L IBR ERW Pipe Carbon Steel API 5L IBR ERW Pipe
API 5L IBR ERW Carbon Steel Pipe CS API 5L IBR Fabricated Pipe
Carbon Steel API 5L IBR Fabricated Pipe API 5L IBR Fabricated Carbon Steel Pipe
CS API 5L IBR EFW Pipe Carbon Steel API 5L IBR EFW Pipe
API 5L IBR EFW Carbon Steel Pipe Carbon Steel API 5L IBR Pipe

IBR API 5L Carbon Steel Pipe Chemical Composition

Grade PSL 1
C (Max) Mn (Max) P (Max) S (Max)
CL I 0.21 0.60 0.30 0.30
CL II 0.21 0.60 0.30 0.30
A 0.22 0.90 0.30 0.30
B 0.26 1.20 0.30 0.30
X42 0.26 1.30 0.30 0.30
X46 0.26 1.40 0.30 0.30
X52 0.26 1.40 0.30 0.30
X56 0.26 1.40 0.30 0.30
X60 0.26 1.40 0.30 0.30
X65 0.26 1.45 0.30 0.30
X70 0.26 1.65 0.30 0.30
Grade PSL 2
C (Max) Mn (Max) P (Max) S (Max)
B 0.22 1.20 0.25 0.15
X42 0.22 1.30 0.25 0.15
X46 0.22 1.40 0.25 0.15
X52 0.22 1.40 0.25 0.15
X56 0.22 1.40 0.25 0.15
X60 0.22 1.40 0.25 0.15
X65 0.22 1.45 0.25 0.15
X70 0.22 1.65 0.25 0.15
X80 0.22 1.90 0.25 0.15

API 5L IBR CS Pipe Mechanical Properties

PSL 1
Grade Tensile Strength Mpa(psi) min Yield Strength Mpa(psi) min
Psi X 1000 Mpa Psi X 1000 Mpa
CL I 45 310 25 172
CL II
A 48 331 30 207
B 60 414 35 241
X42 60 414 42 290
X46 63 434 46 317
X52 66 455 52 359
X56 71 490 56 386
X60 75 517 60 414
X65 77 531 65 448
X70 82 565 70 483
PSL 2
Grade Tensile Strength Mpa(psi) min Yield Strength Mpa(psi) min C. E. IMPACT ENERGY
Psi X 1000 Mpa Psi X 1000 Mpa PCM IIW J FT/LB
B 60 – 110 414 – 758 35 – 65 241 – 448 0.25 0.43 T/L 27/41 T/L 20/30
X42 60 – 110 414 – 758 42 – 72 290 – 496 0.25 0.43 T/L 27/41 T/L 20/30
X46 63 – 110 434 – 758 46 – 76 317 – 524 0.25 0.43 T/L 27/41 T/L 20/30
X52 66 – 110 455 – 758 52 – 77 359 – 531 0.25 0.43 T/L 27/41 T/L 20/30
X56 71 – 110 490 – 758 56 – 79 386 – 544 0.25 0.43 T/L 27/41 T/L 20/30
X60 75 – 110 517 – 758 60 – 82 414 – 565 0.25 0.43 T/L 27/41 T/L 20/30
X65 77 – 110 531 – 758 65 – 82 448 – 565 0.25 0.43 T/L 27/41 T/L 20/30
X70 82 – 110 565 – 758 70 – 82 483 – 565 0.25 0.43 T/L 27/41 T/L 20/30
X80 90 – 120 621 – 827 80 – 102 552 – 705 0.25 0.43 T/L 27/41 T/L 20/30

CS API 5L IBR Pipe Price List

Leoscor Alloys is one of the most competitive suppliers of pipes and tubes from India. Our prices for API 5L IBR Pipe are very competitive.

Please click on the request a quote button or click here to request the updated price list and ready stock information along with your requirement. Leoscor Alloys maintains a stock of all standard items and can export them at best price for API 5L IBR Carbon Steel Seamless and Welded Pipe.

API 5L IBR Carbon Steel Pipe - Industries & Applications

Our pipes and tubes are used in a wide range of applications and various industries. Below are a few of them:

  • Gas Processing Industries
  • Petrochemical Industries
  • Power Generation Industries
  • Food Processing Industries
  • Chemical Industries
  • Oil & Gas Industries
  • Fertilizers Industries
  • Sugar Industries

IBR API 5L Carbon Steel Pipe Stock Availability

We maintain huge inventories of all standard sizes and grades.  Please send us your complete requirement and we will send you the availability with the best quote for Carbon Steel API 5L IBR Pipe.

Click to send your requirement.

Why Buy API 5L IBR Pipe from Leoscor Alloys

Leoscor Alloys is a leading stockist, distributor, and supplier of API 5L IBR Pipe from India. With more than three decades of experience, we understand the steel industry deeply. We have huge experience of supplying to all major industries across the world. Our team of dedicated experts with stringent quality policy ensures that we supply best-in-class products meeting and exceeding our client’s expectations. Below are a few quick points about why buying from Leoscor Alloys will give you an undue advantage:

  • Huge inventory of all standard sizes and grades.
  • Distributors of all reputed origins and manufacturers.
  • Strict quality control policies and highly experienced team.
  • Strong logistics & delivery channels.
  • Modern Infrastructure with huge storage capacity.
  • An ISO 9000:2015 Certified Company.
